RTV 106 High Temperature Silicone - Red - 327gm

SKU:
SWM000508B01V0001
Availability:
Available for Fast Dispatch.

Bulk discount rates

All Bulk Prices Below Are Quoted Including GST.

Buy 5 - 11 and pay only $32.36 each
Buy 12 - 35 and pay only $29.34 each
Buy 36 - 71 and pay only $27.77 each
Buy 72 - 143 and pay only $26.84 each
Buy 144 or above and pay only $26.05 each
  • Info Image for our RTV 106 High Temperature Silicone; Heat resistant, pasty, professional-grade sealant.
  • A professional-grade, high heat silicone adhesive sealant. RTV 106 withstands continuous exposure to 260°C and is FDA approved for food grade applications. It has a paste like consistency and is extremely durable and long-lasting.
$41.11
Inc. GST
$37.37
Ex. GST
Frequently bought together:

Description

  • Pasty, one-part RTV Silicone for high heat applications up to 260°C (315°C short-term).
  • Can be applied to vertical and overhead surfaces.
  • Performance grade, acetoxy-cure silicones approved by the FDA, USDA and NSF. Also UL recognised and meets the requirements of MIL-A-46106 Gr.3 Type I.
  • Particularly suitable for use in cooking and catering equipment due to its combination of heat resistance and food grade certifications.

RTV 106 High Temperature Silicone from Momentive is a specialised, heat resistant grade of silicone sealant. This silicone has a maximum continuous operating temperature rating of 260°C and will handle short-term exposure to up to 315°C.

It is a pasty, one-part RTV silicone with an acetoxy-base (acetic cure). This industrial grade silicone exhibits excellent adhesive to a wide range of surfaces, including:

  • Metals.
  • Stone.
  • Ceramic.
  • Glass.
  • Silicone Rubber.
  • Many Plastics.

It does not bond well to low surface energy plastics like PTFE or PE and care should be taken when it is used with plastic materials with a sensitive surface as the acetoxy cure cycle may damage these materials.

The pasty nature of Momentive RTV106 makes it suitable for application on vertical or overhead surfaces.

Once cured, RTV 106 has good flexibility and is very long lasting. It exhibits excellent weatherability, ozone and chemical resistance and very good dielectric properties.

Typical Applications for RTV 106 High Temp Silicone Adhesive Sealant.

  • Sealing heating elements.
  • Making high-temperature formed in place gaskets.
  • Bonding of parts in cooking and catering equipment.
  • Sealing around heating equipment.
  • Ventilation work.
  • Pump sealing.
  • Sealing and insulating appliances and electronics.

RTV 100 Series Silicone Downloads & Resources

RTV 106 Series Silicone Specifications.

Consistency / Viscosity Paste
Application Rate 400 grams / minute
Specific Gravity 1.07
Tack-Free Time 20 Minutes
Tensile Strength1 26 kg/cm²
Elongation 400%
Hardness 30 Shore A
Tear Strength 7 kg/cm
Shear Strength² 14 kg/cm²
Peel Strength 7 kg/cm
Electrical Properties
Dielectric Strength 20 kv/mm
Dielectric Constant @ 60 Hz 2.8
Dissipation Factor @ 60 Hz 0.001
Volume Resistivity 3x1014 ohm-cm
Thermal Properties³
Brittle Point -60°C
Maximum Continuous Operating Temperature 260°C
Maximum Short-Term Operating Temperature 300°C
Additional Information³
Linear Shrinkage 1%
Thermal Conductivity 0.0005 cal/sec/cm²

All values measured after 3 days cure at 25°C with 50% relative humidity.
(1) At 100% cohesive failure.
(2) At 100% cohesive failure using a 1” x 8” stainless steel screen at 180° pull angle.
(3) Information is provided for convenience only. These properties are not tested on a routine basis.

Please Note
These silicones were not designed for and should not be used for applications intended for permanent implantation into the human body. These silicones are not for use in delicate electrical and electronic applications in which the corrosion of copper, brass or other sensitive metals is undesirable.

For more information on our RTV 100 Silicone, including specifications and approvals, please see our RTV 100 Technical Data Sheet.


Quick Links to Related Categories and Solutions

Browse Our Whole Range of Momentive RTV100 Silicones
Browse Our Range Of Silicone Adhesives & Sealants.
Browse our Dispensing Equipment and Aids Range
View AllClose

Additional Information

Colour:
Red
Container Size:
327gm
One Part / Two Part:
One Part
Viscosity:
Pasty
Minimum Continuous Temperature:
-60°C
Maximum Continuous Temperature:
260°C
Short-Term Temperature Resistance:
+315°C
Shore Hardness:
30 Shore A
Skin Over Time:
20 Minutes
Elongation at Break:
400%
Tensile Strength of the Adhesive:
26kg/cm³
Specific Gravity:
1.07
Dielectric Strength:
20 kV/mm
Food Grade / Potable Water Approvals?:
Yes
