Description
- Long-life grease made with MoS2.
- Very strong adhesion and excellent pressure resistance.
- Can be used to lubricate a wide range of equipment types.
- Industrial grade grease manufactured in Germany.
Our AL-M Grease reduces friction and wear over a long period of time and is suitable for roller and friction bearings, seals, grooves and sliding guides. It is also used to lubricate levers, springs, open gears, helical gears and for grease lubrication at all permissable sliding speeds.
This high performance grease from Weicon in Germany is resistant to high pressure and has a high adhesive strength. It is black in colour with a temperature resistance of -20°C to +120°C.
More information on this grease is included in the sections below:
AL-M All Round Lubricant Technical Summary.
| Abbreviation (DIN 51502) | KF 2 K –20 |
|---|---|
| Consistency Assignment (DIN 51818) | NLGI Class 2 |
| Composition | Li/Ca soap / MoS2 / Mineral Oil |
| VKA-TEST (DIN 51350) Welding Load | 3,200 N |
| VKA-TEST (DIN 51350) Goods Load | 3,000 N |
| VKA-TEST (DIN 51350) Spherical Cap Value (1Min/1000N) |
0.5mm |
| Speed Identifying Value (ka . n . dm) | 250,000 |
| Worked Penetration (DIN ISO 2137) | 265 - 295 1/10 mm |
| Water Resistance (DIN 51807) | 1 – 90 |
| Kinematic Viscosity (DIN 51562) at +40°C |
185mm²/s |
| Kinematic Viscosity (DIN 51562) at +100°C |
14mm²/s |
AL-M Application Areas.
| Rolling Bearings | Y |
|---|---|
| Sliding Bearings | Y |
| Chains | |
| Joints | Y |
| Levers | Y |
| Sliding Guides | Y |
| Linear Guide Systems | |
| Spindles | Y |
| Spline Shafts | Y |
| Camshafts | Y |
| Springs | Y |
| Open Gears | Y |
| Worm Gears | Y |
| Cables |
Specifications
Technical Specifications for AL-M Grease.
| Abbreviation (DIN 51502) | KF 2 K –20 |
|---|---|
| Consistency Assignment (DIN 51818) | NLGI Class 2 |
| Composition | Li/Ca soap / MoS2 / Mineral Oil |
| Colour | Black |
| Density at +20°C (+68°F) (DIN 51757) | 0.92 g/cm³ |
| VKA-TEST (DIN 51350) Welding Load | 3,200 N |
| VKA-TEST (DIN 51350) Goods Load | 3,000 N |
| VKA-TEST (DIN 51350) Spherical Cap Value (1Min/1000N) |
0.5mm |
| Speed Identifying Value (ka . n . dm) | 250,000 |
| Worked Penetration (DIN ISO 2137) | 265 - 295 1/10 mm |
| Water Resistance (DIN 51807) | 1 – 90 |
| Drop Point (IP 396) | > 170°C |
| Kinematic Viscosity (DIN 51562) at +40°C |
185mm²/s |
| Kinematic Viscosity (DIN 51562) at +100°C |
14mm²/s |
| EMCOR Corrosion Test (DIN 51 802): | 0 / 0 |
| Temperature Resistance | -20°C to +120°C |
| Storage Stability | 24 Months Minimum |
Application Type Compatability for AL-M Grease.
| Rolling Bearings | Y |
|---|---|
| Sliding Bearings | Y |
| Chains | |
| Joints | Y |
| Levers | Y |
| Sliding Guides | Y |
| Linear Guide Systems | |
| Spindles | Y |
| Spline Shafts | Y |
| Camshafts | Y |
| Springs | Y |
| Open Gears | Y |
| Worm Gears | Y |
| Cables |
AL-M Grease Compatability with Rubber Sealing Materials.
| ACM – Acrylate Rubber | ++ |
|---|---|
| CR – Chloroprene Rubber | + |
| CSM – Chlorosulfonated PE Rubber | ++ |
| EPDM – Ethylene Propylene Diene Rubber | 0 |
| FMK – Fluorocaoutchoc / Viton | ++ |
| NBR – Nitrile Butadiene Rubber | ++ |
| NR – Natural Rubber | 0 |
| SBR – Styrene Butadiene Rubber | 0 |
| SQM/MVQ – Silicone Rubber | ++ |
AL-M Grease Compatability with Plastic, Polymer-Based Sealing Materials.
| ABS | ++ |
|---|---|
| CA – Cellulose Acetate | ++ |
| EPS – Expanded Polystyrene | ++ |
| PA – Polyamide | ++ |
| PC – Polycarbonate | 0 |
| PE-UHMW – Ultra High Molecular Weight Polyethylene (UHMWPE) |
++ |
| PE-LD Polyethylene with Low Density (LDPE) | + |
| PET – Polyethyleneterephtalate | ++ |
| POM – Polyoxylmethylene | ++ |
| PP – Polypropylene | ++ |
| PPO – Polyphenylene Oxide | ++ |
| PS – Polystyrene | + |
| PTFE – Polytetrafluoroethylene | ++ |
| PUR – Polyurethane | + |
| PVC – Polyvinylchloride | ++ |
| TPE – Thermoplastic Elastomers | 0 |
Compatibility Key Information.
++ = Compatible.
+ = Compatible to a limited extent.
0 = Not Compatible.
The stated compatibility and resistance levels are based on laboratory tests and literature notices. A guarantee cannot be provided due the large number of raw materials used on the one hand the complex chemical and morphological structure of the polymers on the other. In critical application cases we recommend that you carry out tests and/or consult with the Weicon application technology department.
| SKU | SWM000513B01 |
|---|---|
| Model # | 26400000 |
| Brand | Weicon |
